Self-Supporting & Guy Capable, Fully Automated Heavy-Duty Tower Systems ~ Tower-Integrated Tilt System ~ Mobile and Foundation Applications

• Greatest self-supporting and guy capable survivability of any comparable lattice steel telescopic structure – No guy wires required at any elevation to a maximum wind-load and design wind velocity
• Tower secured to ITS’ hydraulic tilt base assembly or installed in the fixed vertical position
• Certified compliance with the ANSI TIA/EIA 222-G Standard – Tower Legs: seamless, mechanical tubing – HSS-ASTM DOM 1026 alloy/A513 to 95Ksi yield strength – solid rod bracing-ASTM A36, 100% hot-dipped galvanized per ASTM A123
• Elevations to +130’0” (39.6m) AGL; Configurations with wind survivability in excess of 130 mph (209 kph); Tower load Capacity to 550 lbs (250 kg) – upgrade to 650 lbs (295 kg); 120-220VAC/60-50Hz Configurations
• MIL-STD-810E, MIL-STD-1472, MIL-STD-454 used as guides in design and manufacturing processes; Certified to AWS D1.1; ISO 9001:2015 Quality Registration
• Direct drive, extreme environment tower operating systems – No exposed belts or chains – Aircraft quality tower cables, stainless pulleys, solid-state circuitry – Integrated Safety Features throughout
• Extended tower and transport lock mechanisms – Redundant cabling for increased safety – LED warning and tower operating lamps
